quickly view:
Custom-made (According to drawings or customer requirements)
1) Drive: Electric / hydraulic
2) Configuration: Single or double drum with / without warping end
3) Wire drum: Steel wire rope drum
4) drum type: LBS grooving drum
5) Rated pull (1st layer): 10 to 2500KN
6) Brake: Holding 1.5 times the rated pull (static, first layer)
7) Paint: As per your specifications
Specifications of hydraulic winch for oil well drilling
| Model | LBS4/110 | LBS15/100 | LBS17/60 | LBS19/100 |
| Pressure Rating | MPa | 16.6 | 16.6 | 16.6 | 16.6 |
| psi | 2400 | 2400 | 2400 | 2400 |
| Max.Pull | kN | 30 | 50 | 160 | 160 |
| US ton | 3.3 | 5.5 | 17.6 | 17.6 |
| Max.Line Speed | m/min | 23 | 11 | 5.8 | 5.8 |
| ft/min | 73 | 36 | 19 | 19 |
| Wire Rope Diameter | mm | 12.7 | 20.5 | 28 | 28 |
| in | | | 13/32 | 13/32 |
| Rope storage | m | 110 | 100 | 60 | 100 |
| ft | 360 | 328 | 197 | 328 |
| Size | mm | 810×490×500 | 880×520×710 | 1340×930×900 | 1520×930×900 |
| in | 32×19×20 | 35×21×28 | 52.8×36.6×35.4 | 59.5×36.6×35.4 |
| Weight | kg | 490 | 490 | 1150 | 1250 |
| lb | 1080 | 1080 | 2530 | 2750 |
Our product advantage :
We use the LBS groove design for the winch drum .Every LBS drum is custom engineered. It is designed and produced specifically to meet the application for which it is used. The groove pattern is engineered to suit the rope's length, diameter and construction type
Company services
1. Our company specialized in design and produce various types of electric and hydraulic anchor windlass , mooring winch, luffing crane and boat plane and rack, winch, engineering winch, cable winch and towing winch(The main drum is used LBS grooved drum)
2. One year of warranty
3. The engineer can provide overseas service
4. Quick and responsible after-sales service
5. Very competitive price
Feature
1. Precision needle bearing used in high-load areas offering lower friction level and longer life.
2. Electrical parts protected by steel box from rain;
3. Large load capacity and rope capacity for using;
4. Steel boxes equip with lock to avoid other staffs in addition to operator to operate winches;
5. Gear reducer driving type
6. It could lift, drag and drop vertically, obliquely;
7. Winch adopt LBS grooving drum to reduce damage and replacement of wire rope
8. Rope winding orderly, safe and reliable on performance
9. The big curvature, fiber oil lubrication, galvanized cover of the wire rope extend its service life
10. Corrosion resistant painting.
11. Running stably, Reliable operation with low noise (no exceed 85dB).
12. Pass 1.25 times static overload test;
Product Tags:
|
|
Electric Mining Hoist Winch for Platform and Emergency Lifting Images
|
